• Spiralast heating coil: The coil is a Hydro Tek manufactured SpiraLast heating coil. Robotically fused 1/2" schedule 80 steel pipe is cold rolled to protect the steel pipe from fatigue and the spiral coil is then surrounded by ceramic insulation and stainless enclosure with double-wall end caps. Ask us about the Lifetime Coil Warranty.
• Ready to Work when you are:
  No need to fill fuel tanks or hunt down a water supply when machine is directly plumbed into natural gas and water lines. The pressure washer can be housed indoors, away from the elements, while locating the wash station remote outdoors.
• Clean and Efficient Heating System:
  24v automatic electronic ignition on low emission natural gas burner. Liquid Propane conversion option or diesel heated option is available on any model.
• Belt Driven pump:
  Low RPM drive – cooler, quieter, continuous duty performance. These industrial triplex pumps feature ceramic plungers for long life. EZ Align™ pump rail system for belt tensioning with a simple adjustment bolt.

• NEMA4 Water Tight Electrical Box:
  ETL certified to UL1776 Class 2 for use in wash-down area, exceeds industry standards. Special Hydro Tek control box features easy to use controls and provides instant access to electronics. Standard diagnostic indicators ensure optimal system performance. Dual voltage switch on most 230v models allows you to simply flip a switch to change to 208v power supply.
• Bypass Cool System:
  Worry free pump cooling system prevents pump from overheating with system designed pump bypass feature.
• Durable Frame Construction:
  Welded, powder coated steel, pro-tect-it frame for durability with rustproof stainless coil wrap and front panels.
  Stainless steel frame option as well as an option for stainless back and top panels available.
• Best in Class accessibility:
  Open frame design gives you full access to all components, including EZ Align™ belt tensioning system, electrical box, and burner igniter for efficient preventative maintenance checks.

• Detergent flow metering at full pressur
• Heavy duty industrial motor with standard thermal overload protection.
• Adjustable temperature up to 250°F with steam setting
• Burst disc technology for operator safety.
• Rustproof float tank to regulate incoming water ensuring consistent system performance.
• Heavy duty hose, wand and trigger gun and quick connect nozzles
• Remote ready: Choose an on/off timer remote option or a full function remote option for complete control from the wash site

• Remote Control with Hose, Nozzle, Wand Rack:  Safe, 24 volt remote with full pressure soap output and 100’ cord gives the operator control of all functions both at the machine and
  the remote wash site. Additional wash station remotes can be added.
• Automatic Shutdown:  Adjustable automatic shutdown prolongs pump life and provides worry-free operation.
• CAT Belt Driven pump:  Low RPM drive – cooler, quieter, continuous duty performance. These industrial triplex pumps feature concentrically bored and polished, graphite impregnated ceramic plungers with advanced seal design.
• Ready to Work when you are:  No need to fill fuel tanks or hunt down a water supply when machine is directly plumbed into natural gas and water lines. The pressure washer can be housed indoors, away from the elements, while locating the wash station remote outdoors.
• More Standard Features:
  •  Detergent flow metering at full pressure
  • Quick release nozzles
  • Heavy duty industrial motor with standard thermal overload protection
  • Adjustable temperature up to 250F with steam setting
  • Burst disc technology for operator safety
  • Rustproof float tank to regulate incoming water ensuring consistent system performance
  • Heavy duty hose 50’ / 250F rated
  • Adjustable Pressure Wand

• Bypass Cool System:  Pump cooling system prevents pump from overheating in bypass for worry free operation. (Remote wash station and pressure gage not included on HN Proline™)
• Other Proline Features:
  • Durable Powder Coated frame base
  • Manual On / Off

• Wall mount hose reel
• additional wash station remotes
• draft diverter
• full-feature wall mount remote
• 30-min shut off timer
• hour meter
• downstream soap injection
• stainless steel frame
• stainless panel wrap kit

Specifications may vary, consult factory for custom models Any model can be ordered as liquid propane or diesel heated

• HN20004E2G Tek Sheet
• HN25004E2G Tek Sheet
• HN25004E3G Tek Sheet
• HN25004E4G Tek Sheet
• HN30004E2G Tek Sheet
• HN30004E2C Tek Sheet
• HN35005E3/E4G Tek Sheet
• HN35005E3/E4C Tek Sheet
• HN35006E3/E4G Tek Sheet
• HN Ultimate Exploded View
• HN Proline Exploded View
